High Precision Digital LCR Meter Tester 50HZ to 200kHz Frequency Signal Level 0.01V to 2.00V (10mV Step) True Color TFT LCD LCR Meter Tester with RS232C and Handler Interfaces

Specification Parameters:Cs-Rs,Cs-D,Cp-Rp,Cp-D,Lp-Rp,Lp-Q,Ls-Rs,Ls-Q,G-B,R-X,Z-θrad,Z-θdeg Monitor Parameters:Z, D, Q, θr, θd, R, X, G, B, Y, Vac, Iac, Δ, Δ% Accuracy:0.05% ±5 Frequency:50Hz～200kHz Display Range:L: 0.00001μH - 999999H C: 0.00001pF - 999999μF R,Z: 0.00001Ω - 99.9999MΩ Q: 0.00001 - 999999 θ(deg): -90.0000°- 90.0000° θ(rad): -3.14159 – 3.14159 Δ%: -999.999% - 999.999% D:0.00001 ～ 9.99999 Source Resistance:30Ω 50Ω 100Ω Range:9 ranges, Automatic, Manual, Nominal Display Max:6 dgt, principle parameter: 999999; sub parameter: 999999; monitor parameter: 999999 Signal Level:0.01V - 2.00V (10mV Step) Speed:30 t/s, 10 t/s, 6 t/s, 3 t/s 1 - 256 times average is available Comparator:14-bin sorting, 10-bin GD, 1-bin NG, 1-bin AUX, 2-bin principle parameter NG Count function: Max - 999999 List Test:10 groups frequency and level scanning test Adjustment:Open/Short frequency reset, 3 point frequency and load correction Files:10 group files to save users' setting, 1 group to save system data real-time Interface: RS232C, ExHandler Interface, with standard USB disc interface (article 10000 data) LCR automatic selection, keypad lock, SCPI instruction set, true-color TFT-LCD display Voltage: 90V AC - 250V AC Frequency: 50Hz - 60Hz Power: Max 20VA 264mm(Width)x107mm(Height)x350 mm(Depth); 4kg ATL501: Test cable ATL607: Test fixture ATL600: Short-circuit slice ATL801: 232 Communication cable ATL608 SMD patch clamp ATL508: SMD patch test clip ATS2816B: Data acquisition software ATL508A: SMD patch test clip

• ★●TFT-LCD Display ●Correction: OPEN and SHORT
• ★●Comparator Function: 10 files,14 bins: P1~P9,NG,AUX, HI, IN, LO ●Interface: RS232C and Handler
• ★●Optional Interface: USB ●Test signal monitor: Vm and Im Built-in RS232C and handler interfaces help build an automatic component test system, communicate with the computer and analysis the test results.
• ★●Avarage rate: 1~200times ●Measurement Terminal: 5 terminals AT2816A offers wide frequency range (50Hz~200kHz 0.001Hz Step), programmable signal level (0.01V to 2.00V), auto range with 9 ranges, 30Ω/50Ω/100Ω constant output impedance and easy-to-use operation system.
• ★Key lock function The AT2816A is the use of a high-performance processors and 3.5" TFT LCD screen smart LCR Meter. Since the SMD technology makes AT2816A portability. We rely on highly skilled technical, so that the instrument even more outstanding performance.
